UTS7013A 13.6 GHz Interceptor-Series Signal Analyzer

The UTS7013A is a 13.6 GHz signal analyzer of the UTS7000A Interceptor-Series, covering 2 Hz to 13.6 GHz on a single chassis with no band switching, for commercial wireless, IoT, EMI pre-compliance, and R&D characterization work.

Displayed average noise level reaches −167 dBm/Hz with the preamplifier engaged, phase noise is below −110 dBc/Hz, and frequency resolution is 0.001 Hz. Real-time spectrum analysis is included with 40 MHz analysis bandwidth standard, software-expandable to 85, 160, or 255 MHz through licensed options. Resolution bandwidth spans 1 Hz to 10 MHz across up to 100,001 sweep points with six traces. The instrument uses an 11.6-inch TFT-LCD touchscreen with a full front-panel keyboard, and provides USB 3.0/2.0, LAN, HDMI, 10 MHz reference in/out, and dual trigger inputs.

Nine licensed measurement options run on the same hardware — 5G NR demodulation, vector signal analysis, I/Q capture, EMI pre-compliance, phase-noise measurement, analog demodulation, an advanced measurement kit, and LTE FDD/TDD — expanding the platform to specialized workflows without a second instrument. It suits wide-band signal interception and characterization across cellular, microwave, and emerging high-frequency bands. Certified to CE, cETLus, and RoHS.

Key Features

• Frequency Range=2Hz - 13.6GHz
• DANL=-167dBm/Hz
• RBW=1Hz-3MHz (10% Steps), 4MHz, 5MHz, 6MHz, 8MHz, 10MHz
• Phase Noise=<-110dBc/Hz
• RTSA=40MHz/255MHz
