UTS3032T+ 3.2 GHz Spectrum Analyzer with Tracking Generator

The UTS3032T+ is a 9 kHz to 3.2 GHz spectrum analyzer of the UTS3000T+ Performance-Series, with a built-in tracking generator as a standard feature of the T+ line. A single bench instrument covers signal search, scalar network measurement, and pre-compliance screening without three separate instruments.

Displayed average noise level reaches −161 dBm typical (preamplifier on, a series-wide figure), phase noise stays below −98 dBc/Hz at 10 kHz offset, and full-amplitude accuracy is under 0.7 dB. Resolution bandwidth resolves from 1 Hz to 3 MHz in 1-3-10 steps with a shape factor below 4.8:1, across 10,001 sweep points per trace with four traces and five detector modes. The tracking generator supports scalar frequency-response and insertion-loss measurement on filters, amplifiers, and cables; with an optional VSWR bridge it adds reflection measurement (return loss, VSWR, S11). A 10.1-inch 1280 × 800 capacitive multi-touch display and full SCPI control over USB and LAN (VXI-11) make it scriptable. Analog demodulation, an advanced measurement kit, and EMI pre-compliance are field-installable licensed options.

It suits small hardware teams and contract test benches needing signal search, scalar network checks, and pre-compliance work from one instrument across HF through the sub-3.2 GHz ISM, IoT, and wireless bands.

Key Features

• Frequency Range=9kHz - 3.2GHz
• DANL=-164dBm/Hz
• RBW=1Hz-1MHz (1-3-10)
• Phase Noise=<-98dBc/Hz
• Tracking Generator=Yes
