UT8806EG 6.5 Digit Performance-Series Bench DMM with GPIB
$1 060.00
6.5-digit auto-ranging True RMS bench multimeter with 0.0035% accuracy, dual-display TFT with GPIB interface for automated test system integration. Lab-grade precision for metrology, calibration, and advanced research applications.
In stock
Customer reviews
Reviews only from verified customers
No reviews yet. You can buy this product and be the first to leave a review.
UT8806EG 6.5 Digit Performance-Series Bench DMM with GPIB
Product Details
UPC: 6935750588222
Manufacturer: UNI-T
Warranty: 3 years
Literature: https://instruments.uni-trend.com/download?cate=32
Equipment Type: Bench Digital Multimeter
The UT8806EG is the GPIB variant of the UT8806E 6½-digit Performance-Series bench digital multimeter, with an IEEE-488.2 GPIB interface in place of RS-232. All measurement specifications are identical: 0.0035% basic DC voltage accuracy, 10,000 readings/second maximum reading rate, a 1,999,999-count display, True-RMS, four-wire resistance to 1 GΩ, dual display, and 32 Gb of NAND flash storage.
DC voltage resolves to 0.1 µV and resistance to 10 µΩ, with thermocouple and RTD temperature measurement (−270 °C to 1820 °C, cold-end compensation), a full math/statistics/dB/dBm/Pass-Fail suite, and four display modes. The IEEE-488.2 GPIB bus integrates the instrument directly into established automated-test racks without a USB-to-GPIB adapter, alongside LAN and USB with SCPI, VXI-11, and USBTMC support. RS-232 is not available on this variant.
It suits test environments standardized on the GPIB bus — calibration labs running established procedures, multi-instrument production racks, and teaching labs with existing GPIB-controller infrastructure.
Key Features
- Digits=6.5
- Count=1,999,999
- Accuracy=0.0035%
- True RMS=Yes
- Interface=GPIB, LAN, USB-Device, USB-Host
Specifications
| Display Digits | 6½ (6.5) |
| Resolution Count | 1,999,999 |
| Basic DC Voltage Accuracy | 0.0035% |
| DC Voltage Resolution | 0.1μV |
| DC Current Resolution | 1pA |
| Resistance Measurement Resolution | 10μΩ |
| Maximum Reading Rate | 10,000 rdgs/s |
| True-RMS | Yes |
| Auto-Ranging | Yes |
| Capacitance Range (max) | 100 mF |
| Frequency Counter Range | 3 Hz – 1 MHz |
| AC Frequency Response | 300 kHz |
| Temperature Range | -270°C to 1820°C |
| Temperature Accuracy | 0.5°C |
| Four-Wire Resistance | Yes |
| Dual Display | Yes |
| Math Operations | Statistics, Limits, Pass/Fail, dB, dBm, Relative |
| Internal Storage | 32 Gb NAND Flash |
| Display | 4.3in TFT LCD |
| Display Resolution | 480×272 |
| Touch Screen | No |
| Interface | GPIB (IEEE-488.2) / LAN / USB-Host / USB-Device |
| Remote Command Set | SCPI (VXI-11, USBTMC, IEEE-488.2-style) |
| Certifications | CE | cETLus |
