UT622A LCR Meter
$185.00
Handheld LCR meter with 100 Hz–10 kHz test frequencies and 0.1% accuracy. A portable, affordable component tester for field verification, education, and incoming inspection.
In stock
Customer reviews
Reviews only from verified customers
No reviews yet. You can buy this product and be the first to leave a review.
UT622A LCR Meter
Product Details
UPC: 6935750562215
Manufacturer: UNI-T
Warranty: 3 years
Literature: https://storage.googleapis.com/uni-tdocuments/Meter%20Datasheets/UT622%20Series%20Data%20Sheet.pdf
Equipment Type: LCR Meter
The UT622A is a handheld LCR meter for component measurement in the field, on the bench, and in teaching settings. It measures inductance, capacitance, resistance, impedance, ESR, and D/Q at test frequencies of 100 Hz, 120 Hz, 1 kHz, and 10 kHz with 0.1% basic accuracy, using a 4-wire Kelvin connection for clean low-impedance readings.
Capacitance reads from 0.00 pF to 99.999 mF, inductance from 0.00 µH to 99.999 H, and impedance from 0.0000 Ω to 9.9999 MΩ. Selectable test signal levels, series and parallel equivalent-circuit modelling, open/short correction, auto-ranging, and tolerance sorting support measurement and component grading.
It suits electronics technicians, QC, and instructional use needing portable component characterization.
Key Features
- Test Signal Level=0.1Vrms, 0.3Vrms, 1Vrms
- Impedance=0.0000Ω - 9.9999MΩ
- ESR Range=0.0000Ω - 999.99Ω
- D/Q Range=D: 0.0000 - 9.9999; Q: 0.0000 - 99999
Specifications
| Frequency | 100 Hz, 120 Hz, 1 kHz, 10 kHz |
| Capacitance | 0.00 pF to 99.999 mF |
| Inductance | 0.00 µH to 99.999 H |
| Impedance | 0.0000 Ω to 9.9999 MΩ |
| ESR Range | 0.0000 Ω to 999.99 Ω |
| Accuracy | 0.10% |
| D/Q Range | D: 0.0000 to 9.9999; Q: 0.0000 to 99999 |
| Impedance Phase Range | -179.9° to 179.9° |
| Test Signal Level | 0.1 Vrms, 0.3 Vrms, 1 Vrms |
| Output Impedance | 100 Ω |
| Tolerance Range | 1% to 20% |
| Equivalent Circuit | Series, Parallel |
| Auto Ranging | Yes |
| Auto LCR | Yes |
| Open Short Correction | Yes |
| Test Method | 4-Wire Kelvin |
| Data Logging | Yes |
| Fastest Test Rate | 20 times/s |
| Interface | Mini-USB |
| Data Storage | 500 groups |
| Display Size | 2.8in |
| Display Type | TFT LCD |
| Display Resolution | 320×240 |
| Battery | 3.7 V 1800 mAh Li-polymer |
| Battery Life | 8 hours |
| Ambient Temperature Range | 0 °C to 40 °C |
| Weight | 420 g |
| Dimensions | 93 × 192 × 44 mm |
