UT-P43 DC-25 MHz 20A 100mV/A Current Probe
$910.00
25MHz bandwidth, 20A current probe for oscilloscopes. Measures current waveforms non-invasively in power electronics, motor drives, and switch-mode circuits.
In stock
Customer reviews
Reviews only from verified customers
No reviews yet. You can buy this product and be the first to leave a review.
UT-P43 DC-25 MHz 20A 100mV/A Current Probe
Product Details
UPC: 6935750540831
Manufacturer: UNI-T
Warranty: 3 years
Literature: https://storage.googleapis.com/uni-tdocuments/UT-P43-P44_User_Manual.pdf
Equipment Type: Scope Probe
An AC/DC current probe for oscilloscopes (DC to 25 MHz, 20 A (100 mV/A)). It clamps around a conductor to convert current into a voltage the scope reads, so current waveforms can be captured without breaking the circuit.
Key Features
- Bandwidth=25MHz
- Max Current=20A
Specifications
| Bandwidth | 25 MHz |
| Output Sensitivity | 100 mV/A |
| Max Current | 20 A |
