UDP3305S 4Ch 328W 30V/5A Programmable Linear DC Power Supply

The UDP3305S is a four-channel programmable linear DC power supply with 328 W total output and 1 mV / 1 mA setting resolution. CH1 and CH2 deliver 0–30 V at up to 5 A, CH3 provides a 0–6 V / 3 A logic-level rail, and CH4 supplies a fixed 5 V / 2 A USB charging output; all channel grounds are isolated. Linear regulation holds output ripple under 350 µVrms (5 Hz–1 MHz).

CH1 and CH2 combine in software for up to 60 V in series or 10 A in parallel without external wiring. A 4.3-inch TFT plots live voltage, current, and power waveforms across all channels, and list-output and delay functions run programmable sequences with sine, ramp, and pulse templates. Per-channel OVP/OCP/OTP protection is configurable.

Remote control is provided over LAN, RS-232, and USB-Host with SCPI, plus driverless web-browser control and an external trigger via Digital I/O, suiting it to automated test, embedded prototyping, and sensor characterization.

Key Features

• Voltage Out=30V
• Current Out=5A
• Channels=4Ch
• Power Out=328W
• Programmable=Yes
